Price: $1,675.51
(as of Oct 05, 2022 07:44:45 UTC – Details)
We need about 3 business days to prepare it for you and will send it to you by FedEx, UPS or DHL service. It will take about 6 days for you to get it.
*Specifications:
*Input Rating:
Power:1200W
Current:0-240A
Voltage:0-150V
*CC Mode:
Range:0-24A;Resolution:1mA;Accuracy:0.05%+0.05%FS
Range:0-240A;Resolution:10mA;Accuracy:0.1%+0.05%FS
*CV Mode:
Range:0.1-19.999V;Resolution:1mV;Accuracy:0.03%+0.02%FS
Range:0.1-150V;Resolution:10mV;Accuracy:0.03%+0.02%FS
*CR Mode(Voltage and current input value >=10% full measurement):
Range:0.03-10K Oh;Resolution:16 bit;Accuracy:0.1%+0.1%FS
Range:0.03-5K Oh;Resolution:16 bit;Accuracy:0.1%+0.1%FS
*CW Mode(Voltage and current input value >=10% full measurement):
Range:0-1200W;Resolution:1mW;Accuracy:0.1%+0.1%FS
Range:0-1200W;Resolution:10mW;Accuracy:0.1%+0.1%FS
*Voltage Measurement:
Voltage:0-19.999V;Resolution:1mV;Accuracy:0.015%+0.03%FS
Voltage:0-150V;Resolution:10mV;Accuracy:0.015%+0.03%FS
*Current Measurement:
Current:0-24A;Resolution:0.1mA;Accuracy:0.05%+0.05%FS
Current:0-240A;Resolution:1mA;Accuracy:0.01%+0.01%FS
*Power Measurement(Voltage and current input value >=10% full measurement):
Power:100W;Resolution:1mW;Accuracy:0.1%+0.1%FS
Power:1200W;Resolution:10mW;Accuracy:0.1%+0.1%FS
*Battery Test:Battery Input: 0.1-150V; Max.
Mesurement:Capacity=999AH; Resolution=0.1mA; Test Range=1S-16H
*Dynamic Test:Transition List:0-25kHZ; 2.5A/uS; T1&T2:60uS-999S;
Accuracy:+15% offset+10%FS
*Current soft-startup
Time:1mS;2mS;5mS;10mS;20mS;50mS;100mS;200mS;500mS;1000mS
Accuracy:+15% offset+10%FS
*Short Circuit:
Current(CC):=26.4A/=264A
Voltage(CV): 0V
Resistance(CR):=7mOh
*Temperature:
Operating:0~40oC
Nonoperating:-10oC~70oC
Is Discontinued By Manufacturer : No
Date First Available : February 13, 2015
Manufacturer : EYL Technology
ASIN : B00TJSULH6
